Voltage Step-Down Module, 12V > 5VDC @ 3A
- The VIM-1205-03A will take a 12 Volts input and drops it down to 5 Volts DC.
- This unit can be used in some Ford, Lincoln, Mercury Vehicles with an Amplified system.
- The OEM Amplifier can be take a 12volt trigger but a POP sound maybe heard, using this Module will eliminate that sound !!
Idea Use for:
- OEM Rearview Cameras
- Satellite Radios
- Dash Cams
Specification:
- Input: DC 12V (Max 22V)
- Output: DC 5V 3A (Max 5A)
- Output power: 15W
- Cable length: Approx.13cm
- Size:Approx. 4.7 x 1.3 x 2.7cm(L x W x H)
- One / Pack
- Priced / each
Wiring:
- Red: 12 Volts DC In
- Black: Ground In
- Yellow: 5 Volts DC out
- Black: Ground out
Ford Wiring:
- Connect the Red wire to the aftermarket radio’s amplifier turn on wire.
- Connect the Yellow wire to the vehicles amplifier turn on wire.
- Connect Black wires to chassis ground.
